Penile implant surgery

FDA ApprovedManufacturer warranty applies. Verify the current written Boston Scientific AMS 700 warranty for the country where the implant will be placed.

The AMS 700™ CX is a 3-piece inflatable penile prosthesis designed to provide strong axial rigidity and controlled girth expansion for men with erectile dysfunction who are candidates for penile implant surgery. It uses paired intracavernosal cylinders, a scrotal pump and a separate fluid reservoir, and is one of the most established inflatable penile prosthesis platforms in long-term clinical use.

3-piece hydraulic design — Paired intracavernosal cylinders, scrotal pump and separate reservoir.
Controlled girth expansion — CX primarily expands circumferentially during inflation.
High axial rigidity — Designed to provide strong support for penetrative intercourse.
Established Peyronie’s disease use — Frequently used with penile modeling and additional straightening techniques when required.
InhibiZone™ configurations — Current CX listings include rifampin/minocycline antibiotic-treated configurations.
Long-term durability evidence — Published CX/CXM series include follow-up beyond 10 years.
Multiple cylinder lengths — 12, 15, 18 and 21 cm, with 24 cm listed as special order.
Rear-tip extenders — Allow precise matching to measured corporal length.
Separate fluid reservoir — Provides substantial difference between inflated and deflated states.

AMS 700™ LGX

FDA clearedCE markedManufacturer warranty applies. Verify the current written Boston Scientific AMS 700 warranty in the country where the device will be implanted.

The AMS 700™ LGX is a 3-piece inflatable penile prosthesis designed to provide controllable rigidity with controlled expansion in both penile length and girth during inflation. It is intended for men with erectile dysfunction who are candidates for penile implant surgery and differs from the AMS 700 CX primarily through its longitudinal expansion capability.

3-piece hydraulic system — Two inflatable intracavernosal cylinders, scrotal pump and separate reservoir.
Length + girth expansion — LGX is specifically engineered for controlled longitudinal and circumferential expansion.
Established AMS 700 platform — Long-standing clinical use with substantial published evidence.
InhibiZone™ available — Rifampin and minocycline antibiotic treatment in applicable configurations.
Non-InhibiZone configurations available — Current ordering information includes both options.
Parylene-coated cylinder surfaces — Designed to reduce cylinder-layer friction and improve mechanical durability.
Multiple cylinder lengths — 12, 15, 18 and 21 cm current configurations.
Rear-tip extender compatibility — Allows precise matching to measured corporal length.
Separate fluid reservoir — Supports strong inflation and good deflated concealability.

Coloplast Titan®

Coloplast

FDA — United StatesManufacturer warranty terms vary by country, distributor and date of implantation. Patients should obtain the current written Coloplast warranty applicable in the country where the device is implanted rather than relying on a universal lifetime-warranty claim.

The Coloplast Titan® is a 3-piece inflatable penile prosthesis designed to provide controllable penile rigidity for men with erectile dysfunction who are candidates for penile implant surgery. It uses Bioflex® cylinders, a scrotal pump and a separate fluid reservoir, with a hydrophilic surface treatment that allows the implant to absorb an aqueous solution selected by the surgeon.

3-piece hydraulic design — Paired intracavernosal cylinders, scrotal pump and separate fluid reservoir.
Bioflex® cylinders — Proprietary cylinder material engineered for rigidity and durability.
HydroVANTAGE™ hydrophilic coating — Absorbs an aqueous solution selected by the surgeon during device preparation.
Lock-out™ valve — Reservoir technology designed to reduce unintended auto-inflation.
Touch pump option — Pump configuration designed to facilitate patient inflation and deflation.
Standard and narrow-base configurations — Multiple sizing options accommodate different corporal anatomies.
Girth-focused expansion — Cylinders provide circumferential expansion and rigidity rather than being specifically designed as a length-expanding implant.
MR Conditional — Titan implants are identified by Coloplast as MR Conditional under specified conditions.

Rigicon Infla10®

Rigicon

CE markedManufacturer warranty applies. Verify the current written Rigicon Infla10 warranty applicable in the country where the prosthesis is implanted.

The Rigicon Infla10® is a 3-piece inflatable penile prosthesis designed to restore controllable penile rigidity in men with erectile dysfunction who are candidates for penile implant surgery. The system uses paired inflatable cylinders, a scrotal pump and a separate fluid reservoir, with different cylinder configurations available for girth-focused or length-and-girth expansion.

3-piece hydraulic system — Paired cylinders, scrotal pump and separate reservoir.
X cylinder option — Primarily designed for girth expansion.
AX cylinder option — Designed for length and girth expansion.
Pulse™ pump — Current-generation scrotal pump.
AdaptiveReservoir™ — Separate fluid reservoir with lock-out mechanism.
HydroShield™ coating — Hydrophilic surface designed to absorb an aqueous antimicrobial solution.
EasyClick™ connectors — Component connection system designed for simplified assembly.
Rear-tip extender compatibility — Allows adjustment to measured corporal length.
Penoscrotal and infrapubic implantation options — Product configurations support both common surgical approaches.
Internationally marketed platform — CE-marked and available in multiple countries outside the United States.

AMS 700™ CXR

FDA ClearedManufacturer warranty applies. Verify the current written Boston Scientific AMS 700 warranty for the country where the CXR prosthesis will be implanted.

The AMS 700™ CXR is a 3-piece inflatable penile prosthesis with narrow controlled-expansion cylinders designed for men whose corporal anatomy cannot safely accommodate standard-diameter penile implant cylinders. It is particularly used in challenging cases involving corporal fibrosis, previous prosthesis infection or explantation, ischemic priapism and other causes of restricted corporal space.

Narrow controlled-expansion cylinders — Designed for restricted corporal anatomy.
3-piece hydraulic design — Paired cylinders, scrotal pump and separate reservoir.
Girth expansion — CXR expands circumferentially rather than using dedicated longitudinal expansion.
Fibrosis-focused design — Particularly useful after previous infection, explantation, priapism or severe corporal scarring.
TENACIO™ pump configurations — Current U.S. product line includes TENACIO CXR systems.
MS Pump™ configurations — Established pump configurations remain listed in current product information.
InhibiZone™ available — Rifampin and minocycline antibiotic surface treatment in applicable configurations.
Multiple narrow-cylinder lengths — Current TENACIO configurations include 10, 12, 14, 16 and 18 cm.
Separate reservoir — Retains the standard 3-piece hydraulic architecture.

Coloplast Titan® Narrow Base

Coloplast

FDA ClearedPMA P000006Manufacturer warranty applies. Verify the current written Coloplast warranty for Titan Narrow Base in the country where the implant will be placed.

The Coloplast Titan® Narrow Base is a 3-piece inflatable penile prosthesis with reduced-diameter cylinders designed for men whose corpora are too narrow or fibrotic for standard Titan cylinders. It retains the Titan platform’s Bioflex® construction, hydrophilic HydroVANTAGE™ surface and separate reservoir while providing an inflatable option for complex corporal fibrosis and revision cases.

Narrow Bioflex® cylinders — Designed for restricted or fibrotic corporal anatomy.
3-piece hydraulic system — Paired cylinders, scrotal pump and separate reservoir.
HydroVANTAGE™ coating — Hydrophilic surface absorbs a surgeon-selected aqueous solution.
Lock-out™ reservoir valve — Designed to reduce unintended auto-inflation.
Titan and Titan Touch pump configurations — Availability varies by market.
Penoscrotal and infrapubic options — Both surgical configurations are currently listed.
Current Narrow Base lengths — 11, 14, 16 and 18 cm.
Strong narrow-cylinder rigidity — Bench evidence suggests comparable buckling resistance to AMS 700 CXR.
Potential staged tissue expansion — Selected patients may later become candidates for larger cylinders after prolonged cycling.

ZSI 475®

Zephyr Surgical Implants

CE MarkZephyr Surgical Implants currently states a 5-year warranty for the standard ZSI 475. Patients should verify the written warranty terms, territorial coverage, registration requirements and revision support applicable in the country of implantation.

The ZSI 475® is a 3-piece inflatable penile prosthesis manufactured by Zephyr Surgical Implants for men with erectile dysfunction who are candidates for penile implant surgery. It uses paired inflatable cylinders, a manual scrotal pump and a separate saline-filled pelvic reservoir, with a hydrophilic PVP coating designed to absorb an antimicrobial solution during surgical preparation.

3-piece hydraulic design — Two inflatable cylinders, scrotal pump and separate pelvic reservoir.
Three-layer cylinder construction — Silicone and polyester reinforcement.
PVP hydrophilic coating — Designed to absorb an antimicrobial solution during surgical preparation.
Adjustable sizing system — 13, 16 and 19 cm standard cylinders with proximal and distal extenders.
Large-size configuration — Separate 22 cm configuration for larger corporal measurements.
Manual scrotal pump — Patient-controlled inflation and deflation.
Saline-filled reservoir — Separate pelvic fluid storage.
CE marked — Current family IFU carries CE marking.
5-year manufacturer warranty — Stated on the current standard ZSI 475 manufacturer page.

2-piece inflatable implant

A 2-piece inflatable penile implant is a surgically implanted penile prosthesis used to provide reliable erections for men with erectile dysfunction that does not respond adequately to medications or other conservative treatments. The system consists of two inflatable cylinders placed inside the corpora cavernosa and a connected pump positioned in the scrotum, with the fluid reservoir incorporated into the cylinders rather than placed separately in the abdomen or pelvis. This eliminates the separate reservoir required by a 3-piece prosthesis while providing an inflatable alternative with better concealability than a permanently semi-rigid malleable implant.

Advantages

+Provides an inflatable erection : The patient can increase penile rigidity for intercourse and reduce rigidity afterward.
+Better concealability than a malleable implant : Deflation allows a softer resting state than continuously semi-rigid rods.
+No separate abdominal or pelvic reservoir : The integrated fluid-storage design eliminates reservoir placement.
+Useful in selected patients with challenging pelvic anatomy : Avoiding a separate reservoir can be advantageous after certain pelvic or abdominal procedures.
+Fewer components than a 3-piece prosthesis : The system eliminates one major prosthetic component and its associated reservoir-placement step.
+Provides reliable mechanical rigidity : The implant bypasses vascular erectile dysfunction and creates rigidity mechanically.
+Can be revised or converted : Selected patients can later undergo replacement or conversion to another prosthesis type when necessary.

Trade-offs

−Requires operation of a scrotal pump : Patients need adequate hand strength and dexterity to inflate and deflate the prosthesis.
−Usually less natural flaccidity than a 3-piece implant : Integrated fluid storage can limit how completely the cylinders collapse in the resting state.
−Expansion may be less than with contemporary 3-piece systems : Three-piece implants generally offer greater hydraulic expansion and erection/flaccidity differentiation.
−Risk of infection Deep prosthetic infection : can require device removal or salvage surgery.
−Risk of mechanical failure : Pump, cylinder, valve, or hydraulic problems can eventually require revision.
−Risk of erosion : Prosthetic cylinders can erode through corporal, urethral, or distal penile tissues.
−Risk of pump-related problems : Pump malposition, discomfort, scar fixation, or difficulty operating the mechanism can occur.
−Risk of corporal perforation : Dilation and cylinder insertion can damage corporal tissue, particularly in complex or fibrotic anatomy.
−Does not guarantee increased penile length : The cylinders must be safely sized according to the patient's existing corporal dimensions.
−Less commonly used than 3-piece systems in many contemporary practices : Its specific advantages are most relevant to selected patients rather than making it the default inflatable prosthesis.

3 device models

ZSI 475®

Zephyr Surgical Implants

3-piece hydraulic design — Two inflatable cylinders, scrotal pump and separate pelvic reservoir.
Three-layer cylinder construction — Silicone and polyester reinforcement.
PVP hydrophilic coating — Designed to absorb an antimicrobial solution during surgical preparation.
Adjustable sizing system — 13, 16 and 19 cm standard cylinders with proximal and distal extenders.
Large-size configuration — Separate 22 cm configuration for larger corporal measurements.
Manual scrotal pump — Patient-controlled inflation and deflation.
Saline-filled reservoir — Separate pelvic fluid storage.
CE marked — Current family IFU carries CE marking.
5-year manufacturer warranty — Stated on the current standard ZSI 475 manufacturer page.

Mentor GFS™

Mentor Corporation

The Mentor GFS is a discontinued device with no active manufacturer warranty, replacement programme or spare parts. Mentor Corporation's urology business was acquired by Coloplast in 2006 and the GFS line was not continued. Men with an existing GFS who require device removal or exchange are treated under standard revision penile prosthesis surgery pathways, and all costs are quoted as revision surgery.

The Mentor GFS was a two-piece inflatable penile prosthesis introduced in 1988 for the surgical treatment of severe erectile dysfunction. Its defining feature was the elimination of the separate abdominal reservoir: the pump and fluid reservoir were combined into a single scrotal unit known as a resipump, connected by tubing to two inflatable penile cylinders. A revised version, the GFS Mark II, removed the tubing connectors to improve reliability. Neither model is manufactured today. This page is intended primarily for men who already have a Mentor GFS or Mark II implanted and are considering revision, replacement or conversion to a modern device.

Two-piece inflatable design — Paired cylinders plus a single combined scrotal unit; no abdominal or pelvic reservoir.
Resipump — Combined the intra-abdominal reservoir and the scrotal pump into one scrotal component.
Fixed-girth expansion — Cylinders expanded to a predetermined girth and were available in two widths.
Office-adjustable fluid volume — Saline could be added through the resipump as an office procedure.
Connectorless Mark II revision — The Mark II removed the need for tubing connectors.
No surface antibiotic or hydrophilic coating — Predates both technologies.
Discontinued — Not manufactured, not supplied, no parts, no warranty.

Mentor Mark II

Mentor Corporation

The Mentor Mark II is a discontinued device with no active manufacturer warranty, replacement programme or spare parts. Mentor Corporation's urology business was acquired by Coloplast in 2006 and the two-piece line was not continued. Men with an existing Mark II who require device removal or exchange are treated under standard revision penile prosthesis surgery pathways, and all costs are quoted as revision surgery.

The Mentor Mark II was the second-generation version of the Mentor GFS two-piece inflatable penile prosthesis. Its defining change was the removal of the tubing connectors used in the original design, producing a connectorless system intended to be more reliable. Like the GFS, it used paired inflatable cylinders linked to a 25 mL scrotal component that acted as both pump and reservoir, eliminating the separate abdominal reservoir of a three-piece implant. Short-term studies were encouraging, but longer-term data showed the lowest device survival of any multicomponent inflatable prosthesis it was compared against. The Mark II is no longer manufactured. This page is written for men who already have one implanted.

Connectorless two-piece design — The defining change from the original GFS.
25 mL scrotal resipump — Combined pump and reservoir in a single scrotal component.
No abdominal or pelvic reservoir — Simplified surgical anatomy compared with three-piece devices.
Fixed-girth cylinders in two widths — Expansion limited to a predetermined girth.
Office-adjustable fluid volume — Saline could be added through the resipump as an office procedure.
No antibiotic or hydrophilic coating — Predates both technologies.

malleable penile implant

A malleable penile implant is a surgically implanted penile prosthesis used primarily to provide reliable rigidity for men with erectile dysfunction that does not respond adequately to medications, injections, vacuum devices, or other conservative treatments. The device consists of two bendable semi-rigid rods placed inside the corpora cavernosa, allowing the penis to be manually positioned upward for sexual activity and downward for concealment. Unlike inflatable penile prostheses, malleable implants contain no pump or fluid reservoir, making them mechanically simpler and particularly useful for patients who prioritize ease of use, have limited hand dexterity, or require selected prosthesis salvage or reconstructive procedures.

Advantages

+Simplest penile implant, with no pump, tubing or reservoir
+Significantly lower mechanical failure rate than inflatable implants
+No abdominal reservoir, so no risk of reservoir herniation or erosion into nearby organs
+No manual dexterity needed — you bend the rods rather than operate a pump
+Shorter, simpler operation than a three-piece inflatable
+High-bend rods allow a smaller incision in the corpora, which shortens closure time
+Suits heavily scarred or fibrotic tissue where a bulkier device is hard to place
+Costs considerably less than an inflatable device
+Three-year survival free of revision reported at 99.2% for the newest device across 605 patients
+Modern malleable devices carry hydrophilic coatings
+Useful where an implant is also needed to hold a condom catheter, with satisfaction of 86.5–92.8% reported in that group

Trade-offs

−Concealment is difficult — the penis stays semi-rigid at all times
−Higher risk of erosion than inflatable implants
−Significantly lower patient satisfaction than inflatable implants (odds ratio 3.39 favouring inflatable)
−Significantly lower partner satisfaction (odds ratio 2.32 favouring inflatable)
−No infection advantage — infection rates do not differ significantly from inflatable devices
−No girth expansion; the penis does not widen as it would with an inflatable device
−Permanent and irreversible — erectile tissue is destroyed, and tablets or injections will not work if the device is removed
−Adds no length, and does not restore length already lost
−In one cohort of men with prior radical pelvic surgery, complications reached 28.1% with malleable implants versus 3.9% with inflatable
−Erosion was the leading reason for device removal in that series, at 6.1%
−Accounts for under 20% of implants in Europe and the USA, reflecting surgeon and patient preference
−Long-term data on the newest devices is still limited

4 device models

Coloplast Genesis®

Coloplast

Verify the current written Coloplast Genesis warranty applicable in the country where the prosthesis will be implanted. Warranty duration, replacement terms and exclusions may vary by market.

The Coloplast Genesis® is a malleable penile prosthesis designed to provide permanent internal rigidity for men with erectile dysfunction who are candidates for penile implant surgery. It uses paired trimmable silicone elastomer rods with a silver wire coil core and hydrophilic surface coating, allowing the penis to be manually positioned for intercourse and repositioned downward for concealment without a pump or fluid reservoir.

Malleable / semi-rigid design — Permanent mechanical support without hydraulic components.
Silver wire coil and helix core — Provides rigidity, positionability and resistance to spring-back.
Silicone elastomer construction — Flexible outer prosthetic structure.
HydroVANTAGE™ hydrophilic coating — Absorbs surgeon-selected aqueous solution during preparation.
Three diameters — 9.5, 11 and 13 mm.
Trimmable cylinders — Allows individualized corporal sizing.
Three tail-cap options — Standard, +0.5 cm and +1.0 cm.
Approximately 90° positionability — Allows manual positioning for intercourse and concealment.
No pump or reservoir — Simple patient operation and prosthetic architecture.
No hydraulic moving components — Fewer mechanical failure points than an inflatable system.

Rigicon Rigi10™

Rigicon

FDA 510(k)CE MarkMRIRigicon offers a Product Replacement Lifetime Warranty for Rigi10 in eligible markets, subject to the company's Limited Warranty and local law. Coverage is limited to qualifying device replacement for defects in materials or workmanship and does not cover surgical, hospital, physician, removal or reimplantation costs. Terms should be verified for the implantation country.

The Rigicon Rigi10™ is a malleable penile prosthesis designed to provide permanent internal rigidity for men with erectile dysfunction who are candidates for penile implant surgery. It uses paired bendable rods with Flexible Rod Technology™, a stainless-steel core, HydroShield™ hydrophilic coating and six available diameters, allowing the penis to be manually positioned for intercourse or concealment without a pump or reservoir.

Malleable / semi-rigid design — Permanent structural support without hydraulic components.
Flexible Rod Technology™ — Up to approximately 135° bending capability.
Stainless-steel core — Provides axial structural rigidity.
Titanium-reinforced caps — Reinforce the internal rod construction.
HydroShield™ hydrophilic coating — Present on rods and rear-tip extenders.
Six diameters — 9, 10, 11, 12, 13 and 14 mm.
Two main rod lengths — 23 cm and 25 cm depending on diameter.
SecureFit™ rear-tip extenders — 0.5 and 1.0 cm options supplied.
No pump or reservoir — Simple manual operation.
MR Conditional — Manufacturer specifies scanning conditions at 1.5T and 3.0T.

Tactra™

FDA 510(k) — United StatesK183619Verify the current written Boston Scientific Tactra warranty applicable in the country where the prosthesis will be implanted. Warranty coverage, exclusions and replacement terms may vary by market.

The Tactra™ is a malleable penile prosthesis manufactured by Boston Scientific for men with erectile dysfunction who are candidates for penile implant surgery. It uses paired bendable rods with a Nitinol core and dual-layer silicone construction, providing permanent internal rigidity that can be manually positioned upward for intercourse and downward for concealment without a pump or fluid reservoir.

Malleable / semi-rigid design — No hydraulic components.
Paired cylinders — One implanted in each corpus cavernosum.
Nitinol core — Nickel-titanium structural core designed for rigidity and repeated bending.
Dual-layer silicone — Proprietary silicone construction around the core.
Articulating flex zone — Designed to improve downward positioning and concealment.
Soft rounded distal tip — Designed for distal comfort.
Three diameters — 9.5, 11 and 13 mm.
Cut-to-length sizing — Cylinders can be trimmed intraoperatively.
Rear-tip extenders included — Permit additional anatomical sizing.
No pump or reservoir — Simple mechanical operation.

Zephyr Surgical Implants (ZSI)

Zephyr ZSI 100

CE MarkWarranty terms for the Zephyr ZSI 100 should be confirmed directly with Zephyr Surgical Implants or the implanting centre before surgery, including what the warranty covers, whether it applies to the original patient only, and which country's law governs it. Warranty cover for penile prostheses is generally limited to device replacement and does not extend to surgical, hospital, physician, removal or reimplantation costs.

The Zephyr ZSI 100 is a malleable penile prosthesis made by Zephyr Surgical Implants in Geneva, Switzerland, for men with erectile dysfunction who are candidates for penile implant surgery. It uses two silicone cylinders with an inner metal core, a bi-material central body combining silicone of different hardnesses, and a hydrophilic PVP coating intended to reduce infection risk. Its most distinctive practical feature is that the surgeon can shorten it from both the distal and proximal ends, giving a single device an adjustable length range from 25 cm down to 12 cm. ZSI is the only European manufacturer producing both malleable and inflatable penile implants alongside artificial urinary sphincters. The device is CE marked and is not available in the United States.

Malleable / semi-rigid design — Two cylinders, permanent structural support, no hydraulic components.
Inner metal core — Provides axial rigidity. Core material disputed between sources; verify before publishing.
Bi-material central body — Silicone at 65, 35 and 20 Shore hardness combined along the rod.
Hydrophilic PVP coating — Manufacturer states it works against infection.
Three diameters — 9 mm, 11 mm and 13 mm.
Trimmable from both ends — Adjustable from 25 cm down to 12 cm from a single device.
Soft CF version available — For erectile dysfunction and for maintaining corporal space after implant infection.
NuSil medical-grade silicone — Specified by the manufacturer for long-term durability.
CE marked, ISO 13485 certified — Not available in the United States.
